The Kentix SiteManager is the central management unit for all Kentix installations. It integrates all functional areas such as SmartAccess, SmartMonitoring, SmartPDU and SmartVideo. The SiteManager can manage up to 500 devices from different functional areas and offers the functionality of an alarm center with different transmission paths (network, mobile radio) for alerting. The KentixONE software is already integrated and configuration is conveniently carried out via a web browser. The SiteManager offers flexible installation options, such as top-hat rail mounting on a 35 mm DIN rail or installation in a 19″ IT rack. Power is supplied via an integrated redundancy module with two external power supply units. The SiteManager is therefore the ideal solution for the central control and monitoring of your security infrastructure.
Scope of delivery: SiteManager, 19" mounting bracket, 4G magnetic base antenna (2m cable length), plug-in power supply 100-230VAC/24VDC, C14 power supply adapter, KentixONE-SIM Karte (DE/AT/CH)
Extensions
DoorLock-WA3-IP network reader (MIFARE® DESFire)
KentixONE
LAN (PoE)
RFID
PoE-Splitter
- RFID & PIN, 2-factor auth.
- Arm/disarm buttons
- LED: RED-GREEN-YELLOW
- Integrated PoE Splitter 24VDC
- Protection class: IP54, Indoor/Outdoor
Base package consisting of RFID wall reader with illuminated touch PIN keypad and AccessManager (SmartRelay) with Ethernet and PoE (10/100MBit), integrated web server (HTTPS) mit KentixONE, main-satellite mode for networking additional AccessManagers, reader mounting in switch box or surface mount (optional).A surface-mounted housing (KXC-WA3-SMC) is required for surface mounting.
Extension package DoorLock-DC (MIFARE® DESFire, BLE) for up to 16 doors
KentixONE
LAN (PoE)
Radio (BLE)
RFID
- With DoorLock-DC PRO (IP55)
- AccessManager with LAN (PoE)
- Web-Server (HTTPS) – Smartphone App
- Up to 16 knobs/handles
- Radio range up to 20m
The DoorLock-DC extension package consists of an AccessManager and a door knob. The AccessManager is the control unit for wirelessly networked Kentix DoorLock components and can manage up to 16 doors with DoorLock-DC (door knob) or DoorLock-LE (door handle). In conjunction with a SiteManager, any number of AccessManagers can be networked. The AccessManager is network-compatible and is supplied with power via Power over Ethernet (PoE). The KentixONE software is already integrated via the integrated web server (HTTPS). Configuration is carried out via a web browser and, depending on the operating mode, locally on the AccessManager itself or on a central instance such as the SiteManager. The AccessManager can be mounted on the wall, on the ceiling or in the false ceiling. The supplied antenna can be extended using an optional magnetic base holder with a 1 m connection cable. This means that the AccessManager can be mounted indoors and the antenna outdoors for flexible and secure installation.
Translated with DeepL.com (free version)
MultiSensor with Ethernet (PoE) and Thermal-Image
KentixONE
LAN (PoE)
Radio (BLE)
Sysport (TYPE A)
- Integrated sensors: 9
- Monitored threats: up to 20
- 4-factor early fire detection
- Web server (HTTPS)
- E-MAIL - SNMP-V2/3 - REST-API
- LAN-RADIO (BLE) repeater integrated
The MultiSensor-TI is the latest MultiSensor technology with integrated thermal imaging sensor for monitoring critical system conditions and for early fire detection. In addition to pure thermal monitoring, the sensor can also detect the movement of people. Compared to thermal imaging cameras, the sensor has the advantage that it works in compliance with data protection regulations and intelligently links several sensors for early fire detection. For early fire detection, this means that up to four factors (thermal image, CO, air quality, room temperature) are analysed for reliable detection.The MultiSensor monitors up to 20 threats and an area of up to approx. 40m² depending on the ceiling height. It is connected via Ethernet with PoE (Power over Ethernet) and therefore requires no additional cabling. Operation is possible as a stand-alone sensor with integrated KentixONE software (HTTPS) or via a networked KentixONE system with SiteManager. The sensor is mounted on the ceiling using the mounting bracket supplied. Mounting in an IT rack or on the wall with the 19’ bracket (accessory) is also possible as an option.Detection angle: 90° or 40° (depending on type)Integrated sensors for monitoring: Temperature, air humidity, dew point, smouldering fire (CO), air quality, air pressure, movement, acceleration/vibration (G), two external alarm contacts.Alarm notification via MultiSensor (stand-alone): E-mail, SNMP traps (V2/3), web hooks (REsT-API)Alarm notification via SiteManager (central): SMS, PUSH (app)
MultiSensor-LAN with PoE (Black)
KentixONE
LAN (PoE)
Radio (BLE)
Sysport (TYPE A)
- Integrated sensors: 8
- Monitored threats: up to 19
- Web server (HTTPS)
- E-MAIL - SNMP-V2/3 - REST-API
- LAN-RADIO (BLE) repeater integrated
Network-compatible MultiSensor for complete room monitoring of up to 19 threats. Monitors an area of approx. 20-25m². The connection is made via Ethernet with PoE (Class 1) and therefore requires no additional cabling. Operation is possible as a stand-alone sensor with integrated KentixONE software (HTTPS) or via a networked KentixONE system with SiteManager. The sensor is mounted on the ceiling using the mounting bracket supplied. Optionally, it can also be mounted in an IT rack or on the wall using the 19’ bracket (accessory).Also ideal as an independent room sensor to supplement network monitoring systems (PRTG, Nagios, CheckMK, etc.) via SNMP-V2/3 or REST-API. The sensor can also send alarm e-mails in stand-alone mode.Integrated sensors: temperature, humidity, dew point, carbon monoxide sensor (CO), 360° PIR motion sensor, 3-axis G-sensor, digital input/outputs.
Digital I/O-Module with 16 digital inputs
LAN (PoE)
- 16 digital inputs (for dry contacts)
- connection of external alarm messages
- Integrated web server
- Ethernet 10/100MBit (PoE)
The I/O expansion module connects to an AlarmManager/SiteManager and is used to connect external alarm messages. The communication takes place via Ethernet. Thus, the module can be mounted at any location. The configuration is done in the KentixONE..16 digital inputs for dry-contacts (e.g. air-conditioning, UPS system, external sensors, etc.)
Leakage sensor for detecting water and flooding
Sysport (TYPE A)
- Plug 'n Play connection
- Sensor sensitivity adjustable
- 5-fold cascadable
- Monitored for cable break
The leakage sensor is used to detect water leakage on the floor and is connected to an SiteManager or MultiSensor directly to the Kentix system port (TYP A). It continuously detects conductivity via multiple electrodes directly on the housing or additionally via a sensor cable.The sensor has an integrated point sensor with adjustable sensitivity. The versions with sensor cable (KLS03-ROPE-10/20) detect water in addition to the point sensor over the entire sensor cable length (10/20m). The sensitivity of the point sensor is 1-2ml water, the sensitivity of the sensor cable is approx. 10ml water over 20cm cable length.The leakage sensor can be cascaded up to 5 times and is therefore also suitable for large rooms.
MultiSensor-DOOR (Black) wireless and battery powered
Radio (BLE)
Battery
- Integrated sensors: 6
- Monitored threats: up to 10
- Wireless (BLE)
- Battery (approx. 4 years)
Ultra-compact MultiSensor for intrusion and status monitoring of doors and windows including ambient monitoring of temperature, humidity and dew point. The sensor is additionally equipped with a 3-axis G-sensor and detects vibration and position changes (sabotage detection, attempted break-in, glass breakage).The MultiSensor-DOOR replaces classic door contacts and can be mounted very easily by gluing or screwing it on. The supplied door/window magnet serves as a counterpart for secure opening detection.The MultiSensor-DOOR is battery operated and has a long battery life (up to four years). It is connected to an MultiSenor-LAN via radio (BLE).
Academy
Event
KentixONE Expert Training
Get started now: Become a certified KentixONE expert in just two days
In two days, get to know KentixONE from the ground up, the IoT-based security system that recognises over 40 physical threats and can be used to secure any company and any infrastructure in an all-round intelligent, predictive, smart and, above all, simple way.After the training course, you will have the expertise to install and commission KentixONE. You complete the training with a certificate. Kentix partners naturally retain their status and receive the certification.
Translated with DeepL.com (free version)
Contents
Kentix: Philosophy and portfolio
KentixONE as a complete system
Basics in SmartAccess, SmartMonitoring, SmartVideo:
Topology
Hardware
Installation, commissioning and maintenance
Software structure
Users, roles and authorizations
Parameterization and settings
Service and Support
Basics in SmartPDU
What do I need for the training?
We provide the equipment, you only need to bring your WiFi-enabled laptop - alternatively there is the possibility to connect a network cable to the laptop on site.
Short & sweet
Two days of classroom training at the training center at Kentix headquarters in Idar-Oberstein
Included: Coffee and soft drinks flat rate, snacks, 2x lunch, 1x dinner
The training takes place in small groups up to a maximum of 10 people
Accommodation and travel costs as well as other expenses are borne by the participants.
Our hotel recommendation in Idar-Oberstein:
Parkhotel Idar-Oberstein, Hauptstraße 185, 55743 Idar-Oberstein, bei Buchung Rabattcode "Kentix" nennen, www.parkhotel-idaroberstein.de
Diamant-Hotel, Tiefensteiner Str. 235, 55743 Idar-Oberstein, Zimmer ab 102 Euro, diamanthotel.de
Villa Horbach, Hauptstr. 264, 55743 Idar-Oberstein, Zimmer ab 139 Euro, villahorbach.com
Event
KentixONE Expert Training (English)
Get started now: Become a certified KentixONE expert in just two days
In two days, get to know KentixONE from the ground up, the IoT-based security system that recognises over 40 physical threats and can be used to secure any company and any infrastructure in an all-round intelligent, predictive, smart and, above all, simple way.After the training course, you will have the expertise to install and commission KentixONE. You complete the training with a certificate. Kentix partners naturally retain their status and receive the certification.
Translated with DeepL.com (free version)
Contents
Kentix: Philosophy and portfolio
KentixONE as a complete system
Basics in SmartAccess, SmartMonitoring, SmartVideo:
Topology
Hardware
Installation, commissioning and maintenance
Software structure
Users, roles and authorizations
Parameterization and settings
Service and Support
Basics in SmartPDU
What do I need for the training?
We provide the equipment, you only need to bring your WiFi-enabled laptop - alternatively there is the possibility to connect a network cable to the laptop on site.
Short & sweet
Two days of classroom training at the training center at Kentix headquarters in Idar-Oberstein
Included: Coffee and soft drinks flat rate, snacks, 2x lunch, 1x dinner
The training takes place in small groups up to a maximum of 10 people
Accommodation and travel costs as well as other expenses are borne by the participants.
Our hotel recommendation in Idar-Oberstein:
Parkhotel Idar-Oberstein, Hauptstraße 185, 55743 Idar-Oberstein, bei Buchung Rabattcode "Kentix" nennen, www.parkhotel-idaroberstein.de
Diamant-Hotel, Tiefensteiner Str. 235, 55743 Idar-Oberstein, Zimmer ab 102 Euro, diamanthotel.de
Villa Horbach, Hauptstr. 264, 55743 Idar-Oberstein, Zimmer ab 139 Euro, villahorbach.com
Delivery Contents
- SiteManager with DIN rail mount
- 19" mounting plates for 1U
- Power supply 100-240VAC/24VDC
- Socket adapter C13 for PDU connection
- GSM/4G magnetic base antenna with 3m cable length
- MicroSD card 4GB
- KentixONE-SIM card for activation (etxra cost)
