SmartMonitoring

Kentix MultiSensor® technology monitors up to 37 hazards easily and efficiently. Real-time information and redundant reporting paths ensure fast notifications. Integrable IT-based solution at no additional cost complies with ISO 27001.

Filter
StarterSet SmartMonitoring with MultiSensors (Ethernet-BLE)
KentixONE LAN (PoE) Radio (BLE) Battery Sysport (TYPE A) 4G-Modem
  • Up to 250 devices (LAN/RADIO)
  • Detected threats: up to 37
  • Web-Server (HTTPS) – Smartphone App
  • E-MAIL – PUSH - SMS
  • LDAP - SNMP-V2/3 - REST-API - WEBHOOKS
Starter set for entry into Kentix SmartMonitoring technology for seamless room and building monitoring. Expandable at any time with SmartAccess, SmartVideo and SmartPDU devices. Already integrated KentixONE software via web server (HTTPS) and 4G modem for redundant SMS alarming.Monitoring of:Temperature, humidity, climate control, smoldering fire / fire / fire gases (CO), intrusion / unauthorized access, access to unauthorized sub-areas (racks/cabinets), line loss / cable defects, failure of active system components, failure of services (HTTP,SMTP,VPN etc.), defective equipment fans, mains voltage failure, UPS defect failure, UPS remaining runtime and capacity.Possibility to connect up to 250 MultiSensors via radio and LANIntegrated LTE modem with slot for SIM card SNMP for integration into monitoring systemsAlarming via E-MAIL (SSL), SMS or SNMP trap
Color

€1,895.00 excl. VAT
SiteManager as a hardware appliance for the individual project start
Appliance / Docker KentixONE Sysport (TYPE A) 4G-Modem
  • Up to 250 devices (LAN/RADIO)
  • Detected threats: >40
  • Web-Server (HTTPS) – Smartphone App
  • E-MAIL – PUSH - SMS - VDS2465
  • LDAP - SNMP-V2/3 - REST-API - WEBHOOKS
High-Performance ARM Quad Core Appliance with KentixONEHigh-performance ARM Quad Core Appliance with KentixONE, Fanless, 2x Ethernet 1GBit/100Mbit (LAN1/2), 2x Kentix system port, SD card slot, nano SIM card slot, integrated 4G modem, dual power supply, Power 24VDC/10Watt, Temperature range 0-55°C, Mounting in 19"-1U or 35mm DIN rail, Size (HxWxD) 111x25x76mm, Scope of delivery: SiteManager, 19" mounting bracket, 4G magnetic base antenna (2m cable length), plug-in power supply 100-230VAC/24VDC, C14 power supply adapter, KentixONE-SIM Karte (DE/AT/CH)
Design

Price after login/registration

Log in or register now
MultiSensor with Ethernet (PoE) and Thermal-Image
KentixONE LAN (PoE) Radio (BLE) Sysport (TYPE A)
  • Integrated sensors: 9
  • Monitored threats: up to 20
  • 4-factor early fire detection
  • Web server (HTTPS)
  • E-MAIL - SNMP-V2/3 - REST-API
  • LAN-RADIO (BLE) repeater integrated
MultiSensor with integrated 1024px thermal-cam sensor for 4-factor early fire detection and extented environmental monitoring.Full software on board with integrated web server (HTTPS), standalone operation or connection to Kentix AlarmManager-PRODetection angle: 90°Integrated sensors with monitoring of: Temperature, humidity, dew point, smoldering fire (CO),  air quality, air-pressure, motion, acceleration-vibration (G), two external dry-contacts.Alarm notification via e-mail, SNMP traps (V2/3), web-hooks (REsT-API) or via SiteManager SMS and PUSH.
Field of view
Color

€675.00 excl. VAT
MultiSensor-LAN with PoE (Black)
KentixONE LAN (PoE) Radio (BLE) Sysport (TYPE A)
  • Integrated sensors: 8
  • Monitored threats: up to 19
  • Web server (HTTPS)
  • E-MAIL - SNMP-V2/3 - REST-API
  • LAN-RADIO (BLE) repeater integrated
MultiSensor for comprehensive room monitoring of up to 20 hazards. Monitors an area of approx. 20-25m². Connection is via Ethernet with PoE (Class 1) and thus requires no further cabling. Operation is possible as a stand-alone sensor with already integrated KentixONE software (HTTPS) or via a networked KentixONE system with AlarmManager or SiteManager. It is mounted on the ceiling using the supplied mounting bracket. Optionally, mounting in the IT rack is also possible with the 19" bracket (accessory).Integrated sensors: temperature, humidity, dew point, carbon monoxide sensor (CO), 360° PIR motion sensor, 3-axis G-sensor, digital input/outputs.Also ideal as an independent room sensor to complement network monitoring systems (PRTG, Nagios, CheckMK, etc) via SNMP-V2/3 or REST API. The sensor can also send alarm email in stand-alone mode.
Color

€525.00 excl. VAT
Digital I/O-Module with 16 digital inputs
LAN (PoE)
  • 16 digital inputs (for dry contacts)
  • connection of external alarm messages
  • Integrated web server
  • Ethernet 10/100MBit (PoE)
The I/O expansion module connects to an AlarmManager/SiteManager and is used to connect external alarm messages. The communication takes place via Ethernet. Thus, the module can be mounted at any location. The configuration is done in the KentixONE..16 digital inputs for dry-contacts (e.g. air-conditioning, UPS system, external sensors, etc.)
Variation

Price after login/registration

Log in or register now
MultiSensor-ROOM (black) battery powered and wireless
Radio (BLE) Battery
  • Integrated sensors: 6
  • Monitored threats: up to 15
  • Wireless (BLE)
  • Battery (approx. 4 years)
Wireless MultiSensor for ceiling mounting and monitoring of rooms and areas up to approx. 25m². The MultiSensor-ROOM is battery operated and has a long battery life of up to 4 years. It is connected to a MultiSensor LAN via radio (BLE).Integrated sensors for: Temperature, humidity, dew point, early fire detection, motion, vibration/shock.
Color

Price after login/registration

Log in or register now
Leakage sensor for detecting water and flooding
Sysport (TYPE A)
  • Plug 'n Play connection
  • Sensor sensitivity adjustable
  • 5-fold cascadable
  • Monitored for cable break
The leakage sensor is used to detect water leakage on the floor and is connected to an SiteManager or MultiSensor directly to the Kentix system port (TYP A). It continuously detects conductivity via multiple electrodes directly on the housing or additionally via a sensor cable.The sensor has an integrated point sensor with adjustable sensitivity. The versions with sensor cable (KLS03-ROPE-10/20) detect water in addition to the point sensor over the entire sensor cable length (10/20m). The sensitivity of the point sensor is 1-2ml water, the sensitivity of the sensor cable is approx. 10ml water over 20cm cable length.The leakage sensor can be cascaded up to 5 times and is therefore also suitable for large rooms.
Sensor cable

Price after login/registration

Log in or register now
Temperature sensor IP66 (-50 to + 100 ° C) for KIO7017
  • Temperature sensor Pt1000 class B
  • 3 selectable temperature ranges
  • Protection class IP66
  • Integrated sensor
PT1000 class B outdoor temperature sensor with active current (4-20mA) and voltage output (0-10V).Three selectable temperature ranges (-50°C ... + 50°C; 0°C ... + 50°C; 0°C ... +100°C).Housing protection IP66.Power supply 24VDC/4mA.For connection to I/O module KIO7017.
Design

Price after login/registration

Log in or register now
MultiSensor-DOOR (Black) wireless and battery powered
Radio (BLE) Battery
  • Integrated sensors: 6
  • Monitored threats: up to 10
  • Wireless (BLE)
  • Battery (approx. 4 years)
Ultra-compact MultiSensor for intrusion and status monitoring of doors and windows including ambient monitoring of temperature, humidity and dew point. The sensor is additionally equipped with a 3-axis G-sensor and detects vibration and position changes (sabotage detection, attempted break-in, glass breakage).The MultiSensor-DOOR replaces classic door contacts and can be mounted very easily by gluing or screwing it on. The supplied door/window magnet serves as a counterpart for secure opening detection.The MultiSensor-DOOR is battery operated and has a long battery life (up to four years). It is connected to an MultiSenor-LAN via radio (BLE).
Color

Price after login/registration

Log in or register now
I/O relais adapter for Kentix sytem port (Type A)
Sysport (TYPE A)
  • I/O adapter
  • 2 digital inputs
  • 2 relay outputs
I/O adapter for connection to Kentix system port (Type A) for connecting external IN/ OUTPUTS via the system socket.2x digital input, 2x relay output

Price after login/registration

Log in or register now
Magnet Door-Contact, white, 2m cable
Door contact with open cable. Contact: NO, cable lenght 2 m, color: white, Size: (L x H x W) 11 x 12 x 48 mm, Delivery: Magnet-contact with mounting material

Price after login/registration

Log in or register now
